OGMA's AP26MC, the ultimate monochrome camera for astrophotography with a large 100ke- Full Well.
Highlights:
- Sensor: Sony IMX571 Monochrome CMOS Sensor
- Resolution: 6224 x 4168
- Mega Pixels: 26MP
- Pixel Size: 3.76 μm (square pixels)
- Format: APS-C
- Amp-Glow: Zero Amp-Glow
- Data Interface: USB3.0/USB2.0
- USB Hub: 2 ports to share the USB connection
- DDR3 Buffer: 512MB (4Gbit) sufficient for reliable data transfer over USB3.0 (1Byte = 8bit)
- Full-well: 100Ke-
- Cooling: Up to 40°C below ambient
Like all cooled OGMA cameras, this camera has an anti-dew heater around the sensor protective window.
Bundled with a bonus accessory kit:
- 2" Filter holder ($39 value)
- 2" UV/IR filter ($39 value)
- Back focus shortener
- Spacers and adapters
Reconfigurable for multiple scenarios:
- A default 17.5 mm of back focus for most situations
- A shorter 12.5 mm back focus for when you need more room for accessories
- Perfect for fast optics with the addition of the O'Tilter
Specifications
- Camera Type: Digital still image
- Sensor: Sony IMX571 back illuminated sensor (Monochrome)
- Diagonal: 28.3 mm
- Image Resolution: 26 mega pixels (6224x4168)
- Pixel Size: 3.76µm x 3.76µm
- Image Area: 23.4mm x 15.7mm
- Max FPS at Resolution:
- 16bit:
- 6.8 FPS @ 6224x4168
- 28 FPS @ 3104x2084
- 63 FPS @ 2064x1386
- 8bit
- 13.2 FPS @ 6224x4168
- 37.1 FPS @ 3104x2084
- 110 FPS @ 2064x1386
- 16bit:
- Max FPS at Resolution (Low Noise):
- 16bit
- 3.4 FPS @ 6224x4168 (Low Noise Mode is only available in All Pixel Readout Mode)
- 8bit:
- 12.7 FPS @ 6224x4168 (Low Noise Mode is only available in All Pixel Readout Mode)
- 16bit
- Shutter Type: Rolling shutter
- Exposure Time: 0.1ms – 3600s
- Gain: 1x – 100x
- SNR: 47.1 dB
- Dynamic Range: 86.8 dB (Low Noise Mode)
- Read Noise (LCG): 1.48 – 3.23 e-
- Read Noise (HCG): 1.32 – 0.82 e-
- QE Peak: >80%
- Full Well: 100ke-
- ADC: 16bit
- DDR3 Buffer: 512MB (4Gbit) sufficient for reliable data transfer over USB3.0 (1Byte = 8bit)
- Data Connection Port: USB3.0/USB2.0
- Data Hub: 2 USB ports
- Optical Path Connection: M42 x 0.75mm
- Also, six M2.5 holes matching popular models of filter wheels and OAGs (requires M2.5 screws)
- Protective Window: Double-side coating protective Anti-Reflections (AR) glass
- Spectral Range: 350-1050nm
- Recording System: Still picture and movie
- Camera Dimensions: Diameter 80mm x height 103mm
- Camera Weight: 0.552kg
- Back Focus Distance: 17.5mm
- Cooling: Two stage TEC
- Effective Cooling Temperature: -35℃ below ambient under short exposure/ -40℃ under long exposure(> 1s)
- Operating Temperature: -5℃ to 50℃
- Storage Temperature: -10℃ to 60℃
- Operating Relative Humidity: 0 to 80%
- Supported OS:
- Microsoft® 10 / 11 (32 & 64 bit) OSx(Mac OS X)
- Linux
- MacOS
- Operating Voltage: 12V DC power adapter supplied
- Acceptable range for batteries: 11-14V DC
- 5.5mm plug diameter
- Center positive plug
Please note that some parameters listed in the product specification tables of this website may undergo modifications as part of our continuous efforts to enhance the product's overall performance, usually through firmware updates. We assure you that when changes are made, it is to maximize the product's capabilities and enhance the user experience.
| Product Banner Type | new |
|---|---|
| Free Shipping Graphic | Free Contiguous US Shipping |
| Hide Found a better Shipped Price on Frontend? | No |
Main package contents:
- 1x OGMA AP26MC Monochrome Cooled Astronomy Camera
- 1x Hardside protective case
- 1x 12 Volt power adapter
- 1x High-speed USB3.0A cable
Bonus kit:
- 1x UV/IR Cut 2-inch filter
- 1x Zero Light Leak filter holder
- 1x Back focus shortener (12.5 mm) with M42(m) thread
- 1x Spacer M42 to M42 x 21 mm
- 1x Spacer/Adapter M42(m) to M48(f) x 16.5 mm
- 1x Thread adapter M42(f) to M48(m)
