Large Aperture: M68 opening on both sides
-
Slim Backfocus: 15.5mm
-
De-Rotation support: For Alt-AZ field derotation
-
USB-C Connectivity: Single cable for power and data.
-
Rotates heavy imaging gear. Up to 6Kg
-
Wi-Fi Enabled: Hotspot and Wireless 2.4GHz client support.
-
ASCOM Alpaca Support: Seamless integration with popular software
-
Firmware Upgradability: Future-proof with software updates
The Falcon Rotator v2 is a new large aperture (M68) camera field rotator that impresses with its lightweight, low-profile design. Despite its slim profile, it possesses the remarkable capability to manage and accurately position even heavy image trains.
Operating the Falcon Rotator v2 is a seamless experience, thanks to its compatibility with classic ASCOM, native ASCOM Alpaca drivers and the Unity Platform software. This user-friendly design simplifies the process of automatically and precisely orienting your camera field, making your astrophotography endeavors significantly more convenient and efficient.
Precise rotation
A powerful geared, low backlash stepper motor ensures that rotator will be precisely positioned to the designated degrees.
One Cable Operation
The rotator can be connected with a USB-C cable for both power and data, reducing complexity in your telescope setup. Additionally, it’s Wi-Fi enabled, allowing you to control your field rotation remotely from your mobile phone.
Rated load
Falcon Rotator v2 has been tested at 6Kg or 13 lbs of imaging setup. The mechanical design allows to custom tighten internall bearing that can easily handle high payloads with nearly zero flexure.
Large aperture in a slim design
The Falcon Rotator 2 has an impressively low profile, slim 15.5mm backfocus thickness and features openings on both sides with an M68 (2.67 inches) x 1mm pitch thread.
The motor has been strategically positioned away from the optical axis to ensure it does not interfere with your equipment.
Field De-Rotation support for Alt-Az mounts
Rotator has the mechanical precision to achieve field de-rotation. Supplied Unity Platform calculates Rate of Rotation (RoR) based on the site latitude, target altitude and azimuth position.
By fine-tuning the micro-step drive control of the motor, derotation can achieve an resolution as precise as 5 arc-seconds.
ASCOM Alpaca Native Support
Falcon Rotator v2 offers Alpaca native support and a convenient web interface for easy smartphone control of your device.
ASCOM Alpaca outshines classic ASCOM drivers with its platform independence, modern web standards, streamlined installation, remote control capabilities, extensibility, and open-source options. This ensures superior compatibility and user-friendly performance, making it the preferred choice for advanced astronomy applications.
Falcon Rotator v2 comes equipped with an integrated web server that seamlessly communicates with Alpaca clients natively. This integration enhances the user experience by providing easy access to image-rotation control through ASCOM Alpaca but also monitoring from any device with a web browser such as a smart phone.
Cable Wrap Prevention
Rotator does not allow a clockwise turn above 220 degrees. It will turn anti-clickwise when it has to be moved above 220 degrees.
A nice cable wrap/snag prevention feature out of the box.
Supported by
- ASCOM 6, ASCOM Alpaca
- INDI Framework
Unity Platform Support
Pegasus Astro Unity Platform is theirnew all around application. Its goal is to provide a robust and modern application that is going to support current and future products under one roof.
A modern frontend allows the full control of all Pegasus Astro devices. Moreover, a REST JSON api helps developers from 3rd party software to interact with Pegasus Astro products.
Specifications
- Physical Size: 180mm x 140mm x 56mm
- Material: Anodised Aluminium
- Clear Aperture: M68 / 1mm pitch thread
- Steps per degree: Supports micro-stepping (x2,4,8,16,32)
- Payload: 6Kg / 13.2lbs
- Telescope Side: M68 Opening
- Camera Side: M68
- Back Focus: 15.5mm
- Weight: 0.7Kg / 1.54 lbs)
- Connectivity: USB 2.0 with USB-C
- Operating Power: 5V, 0.9A
| Product Banner Type | new |
|---|---|
| Free Shipping Graphic | Free US Shipping |
| Hide Found a better Shipped Price on Frontend? | No |
- 1 x Falcon Rotator v2
- 1 x USB-C Cable
- 2 x M68M to M54F Adapter
-
Large Aperture: M68 opening on both sides
-
Slim Backfocus: 15.5mm
-
De-Rotation support: For Alt-AZ field derotation
-
USB-C Connectivity: Single cable for power and data.
-
Rotates heavy imaging gear. Up to 6Kg
-
Wi-Fi Enabled: Hotspot and Wireless 2.4GHz client support.
-
ASCOM Alpaca Support: Seamless integration with popular software
-
Firmware Upgradability: Future-proof with software updates
The Falcon Rotator v2 is a new large aperture (M68) camera field rotator that impresses with its lightweight, low-profile design. Despite its slim profile, it possesses the remarkable capability to manage and accurately position even heavy image trains.
Operating the Falcon Rotator v2 is a seamless experience, thanks to its compatibility with classic ASCOM, native ASCOM Alpaca drivers and the Unity Platform software. This user-friendly design simplifies the process of automatically and precisely orienting your camera field, making your astrophotography endeavors significantly more convenient and efficient.
Precise rotation
A powerful geared, low backlash stepper motor ensures that rotator will be precisely positioned to the designated degrees.
One Cable Operation
The rotator can be connected with a USB-C cable for both power and data, reducing complexity in your telescope setup. Additionally, it’s Wi-Fi enabled, allowing you to control your field rotation remotely from your mobile phone.
Rated load
Falcon Rotator v2 has been tested at 6Kg or 13 lbs of imaging setup. The mechanical design allows to custom tighten internall bearing that can easily handle high payloads with nearly zero flexure.
Large aperture in a slim design
The Falcon Rotator 2 has an impressively low profile, slim 15.5mm backfocus thickness and features openings on both sides with an M68 (2.67 inches) x 1mm pitch thread.
The motor has been strategically positioned away from the optical axis to ensure it does not interfere with your equipment.
Field De-Rotation support for Alt-Az mounts
Rotator has the mechanical precision to achieve field de-rotation. Supplied Unity Platform calculates Rate of Rotation (RoR) based on the site latitude, target altitude and azimuth position.
By fine-tuning the micro-step drive control of the motor, derotation can achieve an resolution as precise as 5 arc-seconds.
ASCOM Alpaca Native Support
Falcon Rotator v2 offers Alpaca native support and a convenient web interface for easy smartphone control of your device.
ASCOM Alpaca outshines classic ASCOM drivers with its platform independence, modern web standards, streamlined installation, remote control capabilities, extensibility, and open-source options. This ensures superior compatibility and user-friendly performance, making it the preferred choice for advanced astronomy applications.
Falcon Rotator v2 comes equipped with an integrated web server that seamlessly communicates with Alpaca clients natively. This integration enhances the user experience by providing easy access to image-rotation control through ASCOM Alpaca but also monitoring from any device with a web browser such as a smart phone.
Cable Wrap Prevention
Rotator does not allow a clockwise turn above 220 degrees. It will turn anti-clickwise when it has to be moved above 220 degrees.
A nice cable wrap/snag prevention feature out of the box.
Supported by
- ASCOM 6, ASCOM Alpaca
- INDI Framework
Unity Platform Support
Pegasus Astro Unity Platform is theirnew all around application. Its goal is to provide a robust and modern application that is going to support current and future products under one roof.
A modern frontend allows the full control of all Pegasus Astro devices. Moreover, a REST JSON api helps developers from 3rd party software to interact with Pegasus Astro products.
Specifications
- Physical Size: 180mm x 140mm x 56mm
- Material: Anodised Aluminium
- Clear Aperture: M68 / 1mm pitch thread
- Steps per degree: Supports micro-stepping (x2,4,8,16,32)
- Payload: 6Kg / 13.2lbs
- Telescope Side: M68 Opening
- Camera Side: M68
- Back Focus: 15.5mm
- Weight: 0.7Kg / 1.54 lbs)
- Connectivity: USB 2.0 with USB-C
- Operating Power: 5V, 0.9A
| Product Banner Type | new |
|---|---|
| Free Shipping Graphic | Free US Shipping |
| Hide Found a better Shipped Price on Frontend? | No |
- 1 x Falcon Rotator v2
- 1 x USB-C Cable
- 2 x M68M to M54F Adapter
