- New ED doublet apochromatic optical design
- New lightweight, compact design perfect for wide field astrophotography
- New optical design featuring our proprietary Metallic High-Transmission Coatings™ (MHTC™)
- 62mm aperture
- 400mm focal length
- Fast f/6.45 focal ratio
- One ED element with matched optics
- Adjustable dew shield protects against stray light and condensation on the lens
- Clamshell mounting system with dual finderscope brackets
- 2.4-inch 11:1 precision dual-speed rack-and-pinion style focuser for better load capacity
- V-style dovetail fits most mounts
- Optional reducer/corrector (360mm at F/5.8)
- Hard case included for your travel or storage needs
Building on the foundation of the popular Evostar line of refractors, Sky-Watcher has developed the all new Evolux 62ED Doublet Apo Refractor # S11305. Designed for the savvy astrophotographer looking for a lightweight scope that still packs a punch with key upgrades in the optics and the mechanics, Evolux is a perfect fit for a widefield grab and go setup.
Sky-Watcher’s Evolux apochromatic doublet refractors are the perfect blend of superior extra-low dispersion glass and affordability. The lens assembly utilizes a proprietary combination of matched lenses, delivering tack-sharp stars with charcoal-black, contrast-rich skies. All ED glass elements feature our proprietary Metallic High-Transmission Coatings™ (MHTC™), virtually eliminating all false color while the adjustable dew shield prevents stray light and condensation from affecting your photography.
Evolux comes in a foam-lined aluminum case with a 2.4-inch dual-speed rack-and-pinion-style focuser, dual finderscope brackets, a V-style dovetail, clamshell ring, and adjustable dew shield. Optional reducer/corrector sold separerately (item # S20206).
Specifications:
Optical Info:
- Optical Design: Apochromatic
- Lens Coatings: Fully multi-coated
- Lens Design: ED Doublet (Air Spaced)
- Glass Type:ED Doublet
- Optical Quality: Diffraction limited (1/4 wave)
- Collimatable Cell: No
- Primary Aperture (mm): 62
- F/Ratio: 6.45
- Focal Length (mm): 400
Observational Info:
- Dawes Limit: 1.87
- Rayleigh Limit: 2.25
- Limiting Mag."" 11.44
- Minimum Magnification: 9x
- Maximum Magnification: 122x
Mechanical Specifications:
- Focuser: 2.4" Dual Speed (11:1) Rack & Pinion
- Focuser: Rotatable?: No
- Compression Ring: Yes
- Retractable dew shield: Yes
- OTA material: Aluminum
- OTA Length (Retract/Ext.): 11.5"/14.5"
- Dew Shield diameter: 90mm
- OTA Diameter: 80mm
- OTA Weight (with accessories): 5.5 lbs
- Mounting rings: Yes
- Dovetail type: V-style dovetail
- Dovetail length: 6"
Optional Corrector/Reducer Specifications (sold separately):
- Corrector Name: Evolux 62ED 0.9x reducer kit
- Optional Corrector/Reducer SKU: S20206
- Reduction (reducer only): 0.9x
- Corrector - insertable or thread-on: Thread-on
- Corrector thread size: M56x1 female/M48 male
- Corrector back focus: 55mm
- Corrector illuminated field: 30mm
- Includes one ED element: Yes
- F/Ratio with reducer installed: 5.8
- Focal Length with reducer installed: 360mm
- Corrector adapter needed?: Yes
- Corrector allow for 2" filters?: No (Adapter included with reducer)
Accessories:
- Eyepieces: No
- Diagonal: No
- Mounting Hardware: Clamshell/Dovetail
- Camera Adapter: No
- Flattener or Corrector: No
- Collimation eyepiece: No
- Finder: No
- Case: Yes
- Case Dimensions: 14.25" x 9.5" x 6.5"
- Shipping Weight: 11 lbs.
- Shipping Dimensions: 18" x 13" x 10"
| Manufacturer | Sky Watcher |
|---|---|
| Product Banner Type | discontinued |
| Free Shipping Graphic | Free Contiguous US Shipping |
| Telescope Focal Length | 301 - 400mm |
| Hide Found a better Shipped Price on Frontend? | No |
