Takahashi E-160 Epsilon 160mm f/3.3 ED Astrograph OTA
Ships by Next Business Day
Contiguous US Customers:
All items we sell ship for free within the Contiguous US. Shipping will be via the cheapest shipping method which will vary depending on the items in your order. During checkout, you may also be shown other optional faster shipping choices.
US Customers in Hawaii and Alaska:
Free shipping applies to almost all products. A few large telescopes and mounts are excluded from this free shipping offer. For these items, please contact us to obtain a shipping quote before you check out using the online shopping cart.
International Customers:
Free shipping does not apply to international orders. During check-out, you will be presented with several shipping choices and costs. However, the export of some items may be restricted outside the US due to size or manufacturer restrictions.
The Epsilon series of astrographs are specifically designed for exceptional astrophotography. Takahashi’s proprietary optical design features a hyperbolic, concave primary mirror with a 2 element corrector lens to eliminate spherical aberration and coma. Compared to the conventional Schmidt camera design, the chromatic aberration is reduced by half, even out to large viewing angles.
The E-160ED reflecting telescope has an aperture of 160 mm and a focal length of 530 mm and provides a well corrected flat field for full frame imaging sensors.
Thorough aberration correction is realized by by optimizing the interaction of the hyperbolic mirror and the corrector. By using ED glass in the corrector, a spot image within 3 μm has been achieved at the periphery of a full frame imaging sensor. The E-160ED combines the ease of handling of the E-130D with the high performance of the E-180ED.
The eccentric oblique mirror and the spider vane design are used to suppress the scatter of light similar to the current epsilon models. The method of holding the primary mirror uses the same system as E-180ED. The optical axis adjustment screw of the primary mirror has a structure in which push screws are arranged on both sides of the pull screw. The central cover can be removed to allow for rapid temperature acclimation.
NOTE:
The corrector for the E-160ED cannot be used with the older E-160 OTA. Price includes OTA only. Mount, tripod, tube holder and finder sold separately.
Takahashi E-160ED Specifications
- Optical Design: Hyperbolic Newtonian
- Effective aperture: 160 mm
- Oblique mirror minor diameter: 63 mm
- Correction lens: 2 elements in 2 groups (1 of which is ED glass)
- Focal length: 530 mm
- Focal ratio: 1: 3.3
- Image circle: φ44 mm (angle of view: 4.8°)
- Lens barrel diameter: 204 mm
- Tube length: 580 mm
- Weight: 6.9 kg
- Viewfinder: 6x30 or 7x50, Sold separately
| Free Shipping Graphic | Free Contiguous US Shipping |
|---|---|
| Telescope Focal Length | 501 - 600mm |
| Hide Found a better Shipped Price on Frontend? | No |
- 1x Optical Tube Assembly
- 1x Visual adapter TKP69005
- 1x Visual coupling (S) TKP00103
- 1x Corrector lens TKP59580
- 1x Eyepiece adapter 31.7 TKP00101
