ZWO FF107 Apo 107mm f/7 Petzval Refractor Telescope
Availability: No ETA available from the manufacturer at this time
Contiguous US Customers:
All items we sell ship for free within the Contiguous US. Shipping will be via the cheapest shipping method which will vary depending on the items in your order. During checkout, you may also be shown other optional faster shipping choices.
US Customers in Hawaii and Alaska:
Free shipping applies to almost all products. A few large telescopes and mounts are excluded from this free shipping offer. For these items, please contact us to obtain a shipping quote before you check out using the online shopping cart.
International Customers:
Free shipping does not apply to international orders. During check-out, you will be presented with several shipping choices and costs. However, the export of some items may be restricted outside the US due to size or manufacturer restrictions.
- Quadruplet air-spaced APO designNo need to calculate back focus
- Small and round stars with a central RMS radius of 3um
- Various adapters: M48/M54/M68/M86
- Dual speed (1:10) focuser. Supports both fine and coarse adjustment
- Self-flattening design. No need for a separate field flattener
- Includes hard case
The ZWO FF107 APO is a refractive astrograph with a powerful flatfield optical design which saves you from the expensive cost of a field flattener. It eliminates the trouble of calculating the back focus dstance of the flattener and any possible accessories you need. As long as the target is focused, the whole optical system is perfect for imaging. This makes the whole setting up process much more convenient, and saves your time, allowing you to pay more attention to the image shooting itself.
The FF107 APO is also a nice choice for your visual observation. It fits diagonals as well as various eyepieces and can achieve a perfect focus, and can even be used to observe planets with a super high magnification eyepiece.
The whole design of the telescope is compact and lightweight. The OTA weighs only 5.7kg, and the full package with tube rings and other accessories weighs 6.9kg. It has an aperture of 107mm. The focal ratio is f/7 and focal length is 749mm.
The FF107 APO adopts a 3+1 quadruplet lens structure which contains two pieces of ED glass that can effectively reduce chromatic aberration and enhance clarity and sharpness. It supports the full-frame imaging circle and has a fine spot diagram with tiny distortions of the peripheral stars. The 3" rigid focuser comes with a new type of 360 degree rotator with scales and a finder base. M86, M68, M54, and M48 camera adapters are also attached, and the M48 adapter has a 2" female thread for installing filters.
Quadruplet air-spaced APO
FF107 APO is a quadruplet with two ED glasses which offers excellent control of chromatic and other aberrations.
44mm image circle
FF70 APO supports full frame cameras such as ASI6200 which gives you a larger field of view. The stars are small and round with a central RMS radius of 3um.
Self-flattening design
No need for a separate field flattener, the FF107 APO eliminates the trouble of calculating the back focus distance of the flattener and connecting varius accessories to achieve that distance. You can just connect any possible accessories you need. As long as the target is focused, the whole optical system is perfect for imaging.
Specifications:
- Observing mode: 120mm
- Aperture size: 107mm
- Focal length: 749mm
- Focal ratio: f/7
- Net weight: 5.7kg
- Gross weight: 6.9kg
- Image circle: 44mm
- Objective lens: Quadruplet air-spaced APO (including two ED glass)
- Dew shield OD: 134mm / 5.27"
- Imaging mode:
- 79mm (from the base of M48x0.75 male thread)
- 99mm (from the base of M54x0.75 male thread)
- 119mm (from the base of M61x1 male thread)
- 149mm (from the base of M86x1 male thread)
- Rear-end thread type:
- M86x1-M68x1
- M68x1-M54x0.75
- M54x0.75-M54x0.75
- M52x0.75-M48x0.75
- (M48x0.75 filter thread inside)
- Total length:
- 603mm (including 2" eyepiece holder as dew shield contracted)
- 655mm (including the 4-piece adapter as dew shield contracted)
- 754mm (including 2" eyepiece holder as dew shield fully stretched)
- 806mm (including the 4-piece adapter as dew shield fully stretched)
- Rear end of the 4-piece photographic adapters: M48x0.75
| Free Shipping Graphic | Free Contiguous US Shipping |
|---|---|
| Telescope Focal Length | 701 - 800mm |
| Hide Found a better Shipped Price on Frontend? | No |
- FF107 APO
- Vixen dovetail plate
- A set of 4-piece photographic adapters
- Manual
- Hard case (not pictured)
